Vehicle Fitment & Part Details

This timing belt set for Audi A1 1.0 TFSI includes OE reference 04E198119 and a 163-tooth belt. Supplied kit details include 2 track rollers. Confirm compatibility by matching the listed fitment details, any OEM reference numbers supplied, and VIN/engine/chassis information where variants exist.

Key Details

SKU

K015680XS

Component

Timing Belt Set

OEM References

• Audi / Skoda / VW: 04E198119

Primary Fitment

Audi A1 1.0 TFSI CHZB,DKLD (2015-)

Specs

163 teeth; length 1141 mm; width 20 mm; tooth pitch 7 mm; 2 track rollers

Key Benefits

• Audi / Skoda / VW OE reference 04E198119 is listed for cross-checking before ordering.
• Supplied belt specification includes 163 teeth, 1141 mm length, 20 mm width, and 7 mm tooth pitch.
• Kit data lists 2 track rollers.

OEM Reference Numbers

• Audi / Skoda / VW: 04E198119

Product Specifications

Vehicle Fitment

Includes 43 supplied applications.

View Full Vehicle Fitment (43 applications)

Make	Model	Years	Engine
Audi	A1 1.0 TFSI	2015-	CHZB,DKLD
Audi	A1 1.0 TFSI Sportback	2015-	CHZB,DKLD
Audi	A3 1.0 TFSI [3CYL]	2016-	CHZD
Audi	A3 1.2 TFSI	2013-	CJZA
Audi	A3 1.4 TFSI	2013-	CXSA
Audi	A3 1.4 TFSI	2013-	CMBA
Audi	A3 1.4 TFSI	2014-	CZEA
Audi	A3 1.0 TFSI Sportback	2016-	CHZD
Audi	A3 1.4 TFSI Sportback	2013-	CMBA,CXSA
Audi	A3 1.4 TFSI Sportback	2014-	CZEA
Audi	A4 1.4 TFSI	2015-	CVNA
Audi	Q2 1.0 TFSI	2016-	CHZJ
Audi	Q2 1.4 TFSI	2016-	CZEA
Audi	Q3 1.4 TFSI	2015-	CHPB,CZDA,
Audi	A1 Sportback 30 TF	2019-	DKJA,DKRF
Audi	Q2 30 TFSI	2018-	DKRF
VW	Polo 1.6i Sedan	2018-	CWVB
VW	CrossPolo 1.2 TSI	2014-	CJZD
VW	Golf 7 1.0 TFSI	2017-	CHZC
VW	Golf 7 1.2 TFSI	2013-	CJZA
VW	Golf 7 1.2 TFSI	2014-	CYVB
VW	Golf 7 1.4 TFSI	2013-	CMBA,CXSA
VW	Golf 7 1.4 TFSI	2014-	CZCA,CPVB
VW	Golf 7 1.4 TFSI	2013-	CPTA,CHPA
VW	Golf 7 1.4 TFSI	2016-2017	CZDA,CZEA
VW	Jetta 6 1.4 TSI	2016-	CZCA
VW	Passat 1.4 TSI	2014-	CZEA,CZDA
VW	Polo 1.0 TSI	2015-	CHZB,DKLD
VW	Polo 1.0 TSI Comfort	2018-	CHZL
VW	Polo 1.0 TSI/GT	2015-2018	CHZC
VW	Polo 1.0 TSI Comfort	2018-	CHZJ DKJA
VW	Polo 1.2 TSI Comfort	2014-	CJZC
VW	Polo 1.2 TSI High/Co	2014-	CJZD
VW	Polo Vivo 1.0 TSI	2018-	CHZC
VW	Tiguan 1.4 TSI	2016-	CZDA,CZEA
VW	Tiguan 1.4 TSI	2016-	CZCA,CZDB
VW	Up 1.0	2015-	CHYB
VW	Caddy 1.0 TSI Trendl	2018-	CHZG
VW	Caddy 1.6 Crew Bus	2015-	CWVA
VW	T-Cross 1.0 TSI	2018-	DKJA, DKRF
VW	T-Cross 1.0 TSI	2020-	CHZL,DKLA,
VW	Jetta 6 1.4 TSI	2014-	CZDA,CZTA
VW	New Beetle 1.2 TSI	2014-	CYVD

Fitment Notes

• Always match OEM reference number(s) and vehicle details before ordering. Confirm exact fitment using VIN, engine code, or chassis number if multiple variants exist.

Installation & Maintenance Tips

• Compare the new kit to the removed parts before installation to confirm the belt length, width, tooth count, and roller configuration match.
• Inspect related pulleys, tensioners, and sealing surfaces before fitting the new kit.
• Replace related seals, one-time-use hardware, or ancillary components where applicable during installation.
• Follow the vehicle manufacturer’s workshop procedure and timing alignment method during installation.
• After installation, verify correct belt tracking and confirm quiet operation during initial running checks.

Common Questions

Does this Timing Belt Set fit my Audi A1?
This part (K015680XS) is listed for the fitments shown on this page. Confirm by matching the fitment details and verifying VIN/engine/chassis information where variants exist.

What OEM part numbers does this cross-reference?
Listed cross-references: 04E198119. Match at least one OEM reference to your original part before ordering.

How do I confirm fitment if there are multiple variants?
Use VIN, engine code, and chassis/platform details and compare them to the fitment section above. If unsure, request fitment assistance before ordering.
